Supported CPU
CPU Socket Type AM3
CPU Type Phenom II / Athlon II / Sempron 100 Series
FSB 2600MHz Hyper Transport (5200 MT/s) Chipsets
North Bridge AMD 880G
South Bridge AMD SB710 Memory
Number of Memory Slots 2×240pin
Memory Standard DDR3 1666 (OC)/1333/1066
Maximum Memory Supported 8GB
Channel Supported Dual Channel Expansion Slots
PCI Express 2.0 x16 1
PCI Express x1 1
PCI Slots 2 Storage Devices
PATA 1 x ATA133 2 Dev. Max
SATA 3Gb/s 4
SATA RAID 0/1/10/JBOD Onboard Video
Onboard Video Chipset ATI Radeon HD 4250 Onboard Audio
Audio Chipset Realtek ALC888B
Audio Channels 8 Channels Onboard LAN
Max LAN Speed 10/100/1000Mbps Rear Panel Ports
PS/2 1 x PS/2 keyboard port or PS/2 mouse port
Video Ports D-Sub + DVI
HDMI 1 x HDMI
USB 1.1/2.0 8 x USB 2.0
Audio Ports 3 Ports Onboard USB
Onboard USB 4 x USB 2.0 Physical Spec
Form Factor Micro ATX
Dimensions 9.6" x 8.6"
Power Pin 24 Pin Features
Features Get Ready to Unleash the Power of AMD 6-Core CPU
3x USB Power Boost
On/Off Charge Support
Core Boost Support
EC AOD-ACC Support
50,000 Hours Japanese Solid Capacitors
ATI Hybrid Graphics Technology support
EasyTune6
DualBIOS - Unique Dual Hardware BIOS Protection
