General
Product Type Motherboard - Micro ATX Chipset Type Intel G41 Express / Intel ICH7 Max Bus Speed 1333 MHz Processor Socket LGA775 Socket Max Processors Qty 1 Compatible Processors Core 2 Quad,
Core 2 Duo,
Celeron 400 sequence,
Pentium,
Celeron Memory
Max Supported Memory 8 GB Supported RAM Technology DDR3 SDRAM Supported RAM Speed 800 MHz,
1066 MHz Supported RAM Integrity Check Non-ECC Supported RAM (Registered or Buffered) Unbuffered RAM Features Dual channel memory architecture Graphics
Graphics Controller Intel GMA X4500 Memory Allocation Technology Dynamic Video Memory Technology 5.0 Audio
Type High Definition Audio (8-channel) Audio Codec Realtek ALC887 Compliant Standards High Definition Audio LAN
Network Interfaces Gigabit Ethernet Modem None Expansion / Connectivity
Expansion Slot(s) 1 x Processor - LGA775 Socket,
2 x Memory - DIMM 240-pin,
1 x PCI Express x16,
1 x PCI Express x1,
2 x PCI Storage Interfaces Intel ICH7 : ATA-100 - connector(s): 1 x 40pin IDC - 2 device(s),
Intel ICH7 : Serial ATA-300 - connector(s): 4 x 7pin Serial ATA - 4 device(s) Interfaces 1 x Display / video - VGA - 15 pin HD D-Sub (HD-15),
1 x Parallel - IEEE 1284 (EPP/ECP) - 25 pin D-Sub (DB-25),
1 x Keyboard - Generic - 6 pin mini-DIN (PS/2 style),
1 x Mouse - Generic - 6 pin mini-DIN (PS/2 style),
1 x Network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45,
4 x Hi-Speed USB - 4 pin USB Type A,
1 x Serial - RS-232 - 9 pin D-Sub (DB-9),
1 x Audio - Line-out (rear)/line-in,
1 x Audio - Line-out,
1 x Audio - Line-out (center/subwoofer)/microphone Additional Connectors (Optional) 4 x Hi-Speed USB Power Connectors 4-pin ATX12V connector,
24-pin main power connector Features
BIOS Type AMI BIOS Features ACPI 2.0 support,
ASUS MyLogo2,
ASUS EZ Flash,
DMI 2.0 support,
WfM 2.0 support,
SMBIOS 2.5 support Hardware Features Audio jack detect technology,
ASUS Stepless Frequency Selection (SFS),
ASUS AI NET2,
ASUS Anti-Surge Protection,
CrashFree BIOS 3,
ASUS EPU (Energy Processing Unit),
C.P.R. (CPU Parameter Recall),
ASUS Turbo Key,
ASUS Express Gate,
ASUS Q-Fan Miscellaneous
Software Included ASUS Live Update,
ASUS PC Probe 2 Microsoft Certifications Certified for Windows Vista Compliant Standards ACPI 2.0,
Plug and Play,
RoHS Width 9.6 in Depth 7.9 in
